Parameter
|
| Model |
5203 |
| Manufacturer |
Baojiu Intelligent Control |
| Drive Type |
Electric |
| Lifting Method |
Electric |
| Operation Type |
Sit-on |
| Rated Load Capacity |
3000kg |
| Load Center Distance |
500mm |
| Front Overhang |
480mm |
| Curb Weight |
3950kg |
| Tire Type |
Solid Tires |
| Wheelbase |
1980mm |
| Front Wheel Track |
1060mm |
| Rear Wheel Track |
1000mm |
| Number of Drive/Load Wheels |
2/2 |
| Front Tires |
650-10 |
| Rear Tires |
17*7-8 |
| Free Lift Height |
100mm |
| Maximum Fork Height |
3000mm |
| Minimum Mast Height |
2060mm |
| Overhead Guard Height |
2050mm |
| Maximum Height During Operation |
4050mm |
| Overall Length (excluding forks) |
2750mm |
| Overall Width |
1205mm |
| Effective Fork Length |
1220mm |
| Fork Outer Width |
200-1060mm |
| Ground Clearance under Mast |
100mm |
| Turning Radius |
2530mm |
| Travel Speed (loaded/unloaded) |
10/10.5 km/h |
| Lifting Speed (loaded/unloaded) |
180/280 mm/s |
| Gradeability |
15% |
| Mast Tilt Angle (forward/backward) |
6/12% |
| Steering Type |
Hydraulic Power Steering |
| Service Brake |
Hydraulic Brake |
| Drive Motor Power |
7.5kw |
| Lifting Motor Power |
7.5kw |
| Battery Specifications |
Lithium battery |
| Battery voltage/rated capacity |
60V/200AH |
