Technical parameters
|
| Model |
CBD-4 |
| Manufacturer |
Baojiu Intelligent Control |
| Drive Method |
Electric |
| Lifting Method |
Electric |
| Rated Load Capacity |
3000KG |
| Load Center Distance |
600mm |
| Self Weight |
230/250KG |
| Steering Wheel Size |
Φ300X110mm |
| Load Wheel Size |
Φ80X70mm |
| Front Wheelbase |
520mm |
| Number of Steering Wheels/Load Wheels |
1/4 |
| Overall Height |
1580mm |
| Fork Lifting Height |
115mm |
| Maximum Fork Height |
200mm |
| Minimum Fork Height |
85mm |
| Overall Length |
1730/1800mm |
| Overall Width |
550/685mm |
| Fork Width |
550/685mm |
| Effective Fork Length |
1150/1220mm |
| Turning Radius |
1340mm |
| Travel Speed (Loaded/Unloaded) |
4.3/4.5 km/s |
| Lifting Speed (Loaded/Unloaded) |
25/30mm/s |
| Lowering speed (Loaded/Unloaded) |
30/20mm/s |
| Gradeability |
5% |
| Service Brake |
Electromagnetic |
| Drive Motor Power |
48v 1.5kw |
| Lifting Motor Power |
48v 0.85kw |
| Battery Type |
Lithium battery |
| Battery Voltage/Rated Capacity |
48V 32AH |
| Battery Weight |
36.9kg |
