Technical parameters
|
| Model |
CBD-5 |
| Manufacturer |
Baojiu Intelligent Control |
| Drive Method |
Electric |
| Lifting Method |
Electric |
| Rated Load Capacity |
2000-3000KG |
| Load Center Distance |
400-2000mm |
| Self Weight |
180-300KG |
| Steering Wheel Size |
Φ210X70mm |
| Load Wheel Size |
Φ80X70mm |
| Front Wheelbase |
300-2100mm |
| Number of Steering Wheels/Load Wheels |
1/4 |
| Overall Height |
1280mm |
| Fork Lifting Height |
115mm |
| Maximum Fork Height |
200mm |
| Minimum Fork Height |
85mm |
| Overall Length |
800-4200mm |
| Overall Width |
480-2000mm |
| Fork Width |
480-2000mm |
| Effective Fork Length |
800-3600mm |
| Turning Radius |
1000-3800mm |
| Travel Speed (Loaded/Unloaded) |
4.3/4.5 km/h |
| Lifting Speed (Loaded/Unloaded) |
25/30mm/s |
| Lowering speed (Loaded/Unloaded) |
30/20mm/s |
| Gradeability |
5/18% |
| Service Brake |
Electromagnetic |
| Drive Motor Power |
48v 1.0kw |
| Lifting Motor Power |
48v 0.85kw |
| Battery Type |
Lead acid battery/Lithium battery |
| Battery Voltage/Rated Capacity |
48V 32AH |
| Battery Weight |
36.9kg |
