Technical parameters
|
| Model |
CDD20 |
| Manufacturer |
Baojiu Intelligent Control |
| Drive Type |
Electric |
| Lifting Method |
Electric |
| Driving Method |
Pedestrian |
| Rated Load Capacity |
2000kg |
| Load Center Distance |
500mm |
| Net Weight |
600/630/660kg |
| Steering Wheel Size |
Φ210X70mm |
| Load Wheel Size |
Φ80X70mm |
| Auxiliary Wheel Size |
Φ124X50mm |
| Front Wheelbase |
560mm |
| Rear Wheelbase |
525mm |
| Number of Steering Wheels/Load Wheels |
1/2 |
| Fork Original Height |
85mm |
| Fork Lifting Height |
2000/2500/3000mm |
| Mast Original Height |
1500/1750/2000mm |
| Mast Lifting Height |
2425/2930/3460mm |
| Overall Length |
1900mm |
| Overall Width |
800mm |
| Fork Dimensions |
60X160X1150mm |
| Fork Outer Width |
685mm |
| Minimum Ground Clearance of Outriggers |
20mm |
| Turning Radius |
1580mm |
| Travel Speed (Loaded/Unloaded) |
4.0/4.5km/h |
| Lifting Speed (Loaded/Unloaded) |
0.08/0.10 m/s |
| Lowering speed (Loaded/Unloaded) |
0.12/0.10 m/s |
| Gradeability |
4/10% |
| Service Brake |
Electromagnetic |
| Drive Motor Power |
48V/1.0KW |
| Lifting Motor Power |
48V/2.2KW |
| Battery Type |
Lead acid battery |
| Battery Voltage/Rated Capacity |
48V,45AH |
| Battery Weight |
48.9kg |
