Parameter
|
| Model |
CPD25 |
| Manufacturer |
Baojiu Intelligent Control |
| Drive Type |
Electric |
| Lifting Method |
Electric |
| Operation Type |
Sit-on |
| Rated Load Capacity |
2500kg |
| Load Center Distance |
500mm |
| Front Overhang |
465mm |
| Curb Weight |
3600kg |
| Tire Type |
Solid Tires |
| Wheelbase |
1455mm |
| Front Wheel Track |
1030mm |
| Rear Wheel Track |
950mm |
| Number of Drive/Load Wheels |
2/2 |
| Front Tire Size |
23*9-10 |
| Rear Tire Size |
18*7-8 |
| Free Lift Height |
150mm |
| Maximum Fork Height |
3000mm |
| Minimum Mast Height |
2070mm |
| Overhead Guard Height |
2150mm |
| Maximum Height During Operation |
3950mm |
| Overall Length (excluding forks) |
2370mm |
| Overall Width |
1265mm |
| Effective Fork Length |
1220mm |
| Fork Outer Width |
200-1040mm |
| Ground Clearance at Mast Base |
105mm |
| Turning Radius |
2046mm |
| Travel Speed (loaded/unloaded) |
12/13 km/h |
| Lifting Speed (loaded/unloaded) |
300/350 mm/s |
| Gradeability |
20% |
| Mast Tilt Angle (forward/backward) |
8/13° |
| Steering Type |
Hydraulic Power Steering |
| Service Brake |
Hydraulic Brake |
| Drive Motor Power |
7.5kw |
| Lifting Motor Power |
7.5kw |
| Battery Specifications |
Lead acid/lithium battery optional |
| Battery voltage/rated capacity |
80V 230Ah |
