Parameter
|
| Model |
CPD35 |
| Manufacturer |
Baojiu Intelligent Control |
| Drive Type |
Electric |
| Lifting Method |
Electric |
| Operation Type |
Sit-on |
| Rated Load Capacity |
3500kg |
| Load Center Distance |
500mm |
| Front Overhang |
500mm |
| Curb Weight |
4600kg |
| Tire Type |
Solid Tires |
| Wheelbase |
1785mm |
| Front Wheel Track |
1152mm |
| Rear Wheel Track |
944mm |
| Number of Drive/Load Wheels |
2/2 |
| Free Lift Height |
150mm |
| Maximum Fork Height |
3000mm |
| Minimum Mast Height |
2070mm |
| Overhead Guard Height |
2200mm |
| Maximum Height During Operation |
4050mm |
| Overall Length (excluding forks) |
3000mm |
| Overall Width |
1260mm |
| Effective Fork Length |
1220mm |
| Fork Outer Width |
200-1100mm |
| Ground Clearance at Mast Base |
140mm |
| Turning Radius |
2450mm |
| Travel Speed (loaded/unloaded) |
13/15 km/h |
| Lifting Speed (loaded/unloaded) |
310/360 mm/s |
| Gradeability |
20% |
| Mast Tilt Angle (forward/backward) |
8/13° |
| Steering Type |
Hydraulic Power Steering |
| Service Brake |
Hydraulic Brake |
| Drive Motor Power |
16kw |
| Lifting Motor Power |
18kw |
| Battery Specifications |
Lead acid/lithium battery optional |
| Battery voltage/rated capacity |
80V 300Ah (Optional) |
