Parameter
|
| Model |
CPD50 |
| Manufacturer |
Baojiu Intelligent Control |
| Drive Type |
Electric |
| Lifting Method |
Electric |
| Operation Type |
Ride-on |
| Rated Load Capacity |
5000kg |
| Load Center Distance |
500mm |
| Front Overhang |
560mm |
| Curb Weight |
6500kg |
| Tire Type |
Pneumatic Tires |
| Wheelbase |
2000mm |
| Front Wheel Track |
1230mm |
| Rear Wheel Track |
1140mm |
| Number of Drive/Load Wheels |
2/2 |
| Tire Size-Front |
23*9-10 |
| Tire Size-Rear |
18*7-8 |
| Free Lift Height |
140mm |
| Maximum Fork Height |
3000mm |
| Minimum Mast Height |
2250mm |
| Overhead Guard Height |
2400mm |
| Maximum Height During Operation |
4300mm |
| Overall Length |
4200mm |
| Overall Width |
1520mm |
| Effective Fork Length |
1220mm |
| Fork Outer Width |
200-1040mm |
| Ground Clearance at Mast Base |
260mm |
| Turning Radius |
2800mm |
| Travel Speed (loaded/unloaded) |
16/15 km/h |
| Lifting Speed (loaded/unloaded) |
300/330 mm/s |
| Gradeability |
15% |
| Mast Tilt Angle (forward/backward) |
6/12% |
| Steering Type |
Hydraulic Power Steering |
| Service Brake |
Hydraulic Brake |
| Drive Motor Power |
18kw |
| Lifting Motor Power |
25kw |
| Battery Specifications |
Lead acid/lithium battery optional |
| Battery voltage/rated capacity |
80/460 V/Ah |
